产品信息

Part NO. Configuration BVDSS
(V)
VGS
(V)
VGS(TH)
(V)MAX.
ID(A)
25℃
RDS(ON) TYP.(mΩ) 封装形式
(-)10V (-)4.5V (-)2.5V
RZC2300 Single  20 ±12 1.0 3.0 --- 32 40 SOT23
RZC2302 Single  20 ±12 1.0 5.0 --- 23 27 SOT23
RZC8205S Dual 20 ±12 1.5 5.7 --- 23 27 SOT23-6
RZC8205A Dual 20 ±12 1.5 5.7 --- 22 26 TSSOP-8
RZC8808S Dual 19 ±12 1.5 5.0 --- 16 22 SOT23-6
RZC8809S Dual 19 ±10 1.5 6.0 --- 13 18 SOT23-6
RZC3400 Single  30 ±12 1.0 3.0 --- 40 60 SOT23
RZC3400C Single  30 ±12 1.0 5.7 --- 35 40 SOT23-3
RZC2301 Single  -20 ±12 -1.0 -2.8 --- 85 100 SOT23
RZC2305 Single  -20 ±12 -1.0 -4.0 --- 40 55 SOT23
RZC2317 Single  -20 ±12 -1.0 -4.7 --- 32 40 SOT23
RZC4435 Single  -30 ±20 -2.5 -10 16 21 --- SOP-8
RZC3415E Single  -20 ±12 -1.0 -4.0 --- 48 65 SOT23
RZC3401 Single  -30 ±12 -1.5 -3.0 --- 45 55 SOT23
RZC3401C Single  -30 ±12 -1.5 -5.7 --- 45 55 SOT23-3
RZC4606A Complementary 30 ±20 2.5 5.8 24 34 --- SOP-8
-30 ±20 -3.0 -6.5 48 ---
